Introduction

For over 10 years we have specialized in thermal cyclers with proven performance and unmatched combination of features. Just right for every laobratory, whether you run only a few samples per week or perform high-through processes. Thousands of our products are in daily use around the globe, helping secientists, health professionals and laoboratory managers achieve high levels of accuracy and consistency in their work. We believe in giving our customers a choice in how they use our thermal cyclers, supported by excellent service and support.

Which thermal cycler instrument is right for you?

Model Appearance	T960 Gradiente PCR Termociclador	B960	K960	KF960	K640	K160
Block Formats	96×0.2ml(A),54×0.5ml(B),96×0.2ml+77×05ml(C),384well(D)				64×0.2ml(A),36×0.5ml(B)	30×0.2ml(A),9×0.5ml(B), 16×0.2ml+9×0.5ml(C)
Temp Range	0℃~99.9℃	0℃~99.9℃	0℃~99.9℃	0℃~99.9℃	4℃~99.9℃	0℃~99.9℃
Display Interface	7'LCD	5.7'LCD	5.7'LCD	5.7'LCD	4.3'LCD	12864LCD
Max.Heating Ramp Rate	5.0℃/s	4.5℃/s	4.0℃/s	4.0℃/s	2.5℃/s	2.0℃/s
Max.Cooling Ramp Rate	5.0℃/s	4.0℃/s	3.5℃/s	3.5℃/s	2.5℃/s	2.0℃/s
Heating/Cooling adjustable rate	0.1℃/s~4.0℃/s	0.1℃/s~4.0℃/s	0.1℃/s~4.0℃/s	0.1℃/s~4.0℃/s	-	-
Uniformity	≤±0.2℃	≤±0.2℃	≤±0.2℃(20~75℃)	≤±0.2℃(20~75℃)	-	≤±0.3℃(20~75℃)
Accuracy	≤±0.1℃	≤±0.1℃	≤±0.2℃	≤±0.2℃	≤±0.2℃	≤±0.2℃
Gradient Temp Range	30~99℃	30~99℃	30~99℃	-	-	-
Thermal Gradient Span	1~30℃	1~30℃	2~30℃	-	-	-
Gradient Uniformity	≤0.2℃(single row)	≤0.2℃(single row)	≤0.2℃(single row)	-	-	-
Hot Lid Temp	20~110℃	20~110℃	30~115℃	30~115℃	-	-
Temp Control Mode	Block,tube*	Block,tube*	Block,tube	Block,tube	Block	Block
Memory Capacity	2000**	1000**	200	200	9	3
Max.No.of Cycle	999	999	99	99	99	99
Communication	USB2.0/RS 232/RJ45	USB2.0/RS 232/RJ45	USB2.0/RS 232	USB2.0/RS 232	-	Serial port
Intelligent Diagnosis	108	108	-	-	-	-
Size(W×D×H,mm)	380×270×250	380×270×250	380×270×250	380×270×250	370×260×290	160×140×120
Weight(kg)	8.1	7.8	7.2	7.2	4.9	2.2
